Frost or Freeze Damage to Immature Corn
R.L. (Bob) Nielsen
Agronomy Dept., Purdue Univ.
West Lafayette, IN 47907-2054
Email address: rnielsen at purdue.edu
Twitter: @PurdueCornGuy
Forecasts for freezing or near-freezing temperatures when late-planted fields of corn are not yet mature (i.e., not yet at kernel black layer) are naturally concerning to farmers and the grain markets. What are the consequences for grain yield, grain moisture, and harvestability of immature corn damaged by frost or freeze events?
First of all, recognize there is a difference in how the corn plant responds to "simple" frost versus lethal freezing temperatures. Frost can develop on exposed leaves (or cars or rooftops or deck chairs) at air temperatures well above 32ºF (0ºC), especially when skies are clear, humidity is low and winds are calm. Simple frost can damage or kill exposed leaf tissue (but not cars or rooftops or deck chairs). However, "simple" frost usually does not literally kill entire plants. The consensus among many agronomists is that lethal effects of cold temperature on corn occur when air temperatures remain at or below 32ºF for several hours or perhaps only minutes when temperatures dip to 28ºF (-2.2ºC) before increasing again beyond 32ºF.
When a plant experiences damage or death to leaves due to "simple" frost, photosynthesis may continue to limp along if there are any remaining green leaves. Additionally, remobilization of non-structural carbohydrates from the stalk tissue to the immature grain may continue, thus avoiding some of the potential yield loss.
Click image for larger view
However, when plants experience truly lethal cold temperatures, photosynthesis and its related metabolic activities come to a screeching halt, stopping further dry matter accumulation in the grain. Contrary to some public opinion, kernel black layer will eventually develop in grain of plants killed prematurely by lethal cold temperature or other severe late-season stresses. The reduction or lack of available photosynthate (sucrose) appears to contribute to the death of the placental cell tissue at the tips of the kernels, which will slowly collapse into a thin, black layer (Afuakwa et al., 1984).
Premature kernel black layer development can also occur in response to any extended period of severe stress during grain filling (especially late in the grain filling process) that significantly reduces photosynthesis, including cool (sub-optimal) temperatures in September and October, even before a frost or freeze event. Conversely, this may explain why kernel black layer development occurred later than expected in some late-planted Indiana corn fields in 2019. September 2019 was 4 to 7º F warmer than normal statewide (Midwest Climate Watch, MRCC, https://mrcc.illinois.edu/cliwatch/watch.htm). Consequently, photosynthetic rates in late-planted fields that were still relatively healthy were likely higher than expected for September and, therefore, greater than usual amounts of sucrose availability may have delayed the onset of kernel black layer development.
Physiological grain yield loss in response to frost or freeze damage results from the cessation of dry matter accumulation. One of the frequently cited references for yield loss estimates in these situtations is Afuakwa & Crookston (1984). Their research in Minnesota, using 80 and 105 "day" hybrids, suggested that, averaged over 4 hybrids, yield loss due to just the loss of leaves (similar to "simple" frost damage) at soft dough (R4), full dent (R5), and half-milkline was 35, 27, and 6% respectively. On the other hand, yield loss due to whole plant death (as would follow lethally cold temperatures) at soft dough (R4), full dent (R5), and half-milkline was 54, 40, and 12%, respectively. The greater yield losses in response to whole plant death are due to the inability of dead plants to remobilize stored non-structural carbohydrates from the stalk tissue to the kernels.
Another source that could be used to estimate yield loss due to just the loss of leaves (e.g., simple frost) is the defoliation chart from the National Crop Insurance Services corn hail loss instructions (reprinted in Klein & Shapiro, 2011). That reference suggests that 100% loss of leaves at soft dough, dent, and nearly mature (which I interpret to be half-milkline) growth stages would result in yield losses of 41, 23, and 8%, respectively.
In addition to outright physiological yield losses, damage by "simple" frost or lethal freezing temperatures can cause other problems for corn harvest, drying, and storage.
- Frost damage to leaves that does not kill the stalk allows for some cannibalization of non-structural carbohydrates from the stalk tissue to the immature grain. That may be desirable in terms of minimizing yield losses, but the process physically weakens the lower stalk and increases its susceptibility to root and stalk rots (Nielsen, 2019b). Consequently, severe stalk lodging may occur before harvest that increases the risk of mechanical yield loss during harvest.
- Complete and rapid whole plant death due to lethal freezing temperatures may result in affected immature plants literally collapsing to the ground. Not only does this create mechanical havoc with the eventual grain harvest, but ears literally lying on the soil surface for extended periods of time are prone to general deterioration and kernel sprouting.
- The daily rate of field drydown in corn following damage by simple frost or death by lethal cold temperatures is not markedly different than grain moisture loss of corn that matures "normally" (Hicks, et al., 1976). HOWEVER, field drydown apparently is temporarily slowed or delayed immediately after such damage occurs and so gives the illusion that overall field drying rates are slower. Nevertheless, frost or freeze damage will cause a delay in the grain reaching desirable harvest moisture contents, especially when the ensuing days following a frost/freeze event are cool and not conducive for rapid grain drying anyway.
- Making silage from frost-damaged immature corn can be problematic because of excessive whole plant moisture, lower quality, possible mold development on the kernels, and stalk nitrate accumulation (Carter & Hesterman, 1990; Lauer, 2004, 2014; Lee & Herbek, 2004; Singh & Cassida, 2019).
- Frost damage to immature corn may result in smaller than normal kernels that are often misshapen and prone to breakage upon handling. These consequences can create problems with post-harvest grain drying, handling and storage (Hurburgh, 2012; Maier & Parsons, 1996).
One last comment... When freezing temperatures are accompanied by snow, that adds layers of complexities to the problem. Large amounts of wet, heavy snow can literally bring a standing corn crop to its knees, if not completely to the ground, especially when coupled with strong winds. Obviously, this creates challenges in harvesting the downed corn later. Further drydown of immature grain is also compromised when ears are laying on or near the soil surface. Kernel moisture loss on plants that remain standing after a snow storm will continue to occur slowly at rates dependent on temperature, sunshine, and humidity. In worst case scenarios where a corn field remains unharvested throughout the winter, there is evidence from Wisconsin (Lauer, 2010) that grain drydown will continue slowly throughout the winter months.
For more information...
Afuakwa, J.J. and R.K. Crookston. 1984. Using the kernel milk line to visually monitor grain maturity in maize. Crop Sci. 24:687-691.
Afuakwa, J.J., R. Kent Crookston, and R.J. Jones. 1984. Effect of temperature and sucrose availability on kernel black layer development in maize. Crop Sci. 24:285-288.
Carter, P.R. and O.B. Hesterman. 1990. Handling Corn Damaged by Autumn Frost. National Corn Handbook. NCH-57. https://www.extension.purdue.edu/extmedia/NCH/NCH-57.html [URL accessed Oct 2019]
Coulter, Jeff, David Nicolai, and Phyllis Bongard. 2018 (rev.) Early Fall Frost. Univ. Minnesota Extension. https://extension.umn.edu/growing-corn/early-fall-frost [URL accessed Oct 2019]
Hellevang, Ken. 2019. Post-harvest Tips for Late Maturing Corn. Winter Storm Information, North Dakota State Univ. Extension. https://www.ag.ndsu.edu/winterstorm/winter-storm-information-farm-and-ranch-information1/farm-and-ranch-crops-corn/post-harvest-tips-for-late-maturing-corn [URL accessed Oct 2019]
Hicks, D.R., J.L. Geadelmann, and R.H. Peterson. 1976. Drying Rates of Frosted Maturing Maize. Agron. J. 68:452-455.
Hoegemeyer, Tom. 2015. Frost/Freeze Effects on Corn and Soybean. CropWatch, Univ Nebraska Extension. https://cropwatch.unl.edu/frostfreeze-effects-corn-and-soybean [URL accessed Oct 2019]
Hurburgh, Charles. 2012 (rev.) Frost Damage to Corn and Soybeans. Iowa State Univ. Extension pub. #PM1635. https://store.extension.iastate.edu/Product/pm1635-pdf [URL accessed Oct 2019]
Klein, Robert and Charles Shapiro. 2011. Evaluating Hail Damage to Corn. Univ. Nebraska Extension, publication #EC126. http://extensionpublications.unl.edu/assets/pdf/ec126.pdf [URL accessed Oct 2019]
Lauer, Joe. 2004. Guidelines for Handling Corn Damaged by Frost Prior to Grain Maturity. Corn Agronomy, Univ. Wisconsin. http://corn.agronomy.wisc.edu/WCM/W156.aspx [URL accessed Oct 2019]
Lauer, Joe. 2010. Drying Progress of Corn Standing in the Field over Winter. Corn Agronomy. Univ of Wisconsin. http://corn.agronomy.wisc.edu/AA/A076.aspx [URL accessed Oct 2019]
Lauer, Joe. 2014 (updated). Frost. Corn Agronomy, Univ. of Wisconsin. http://corn.agronomy.wisc.edu/Management/L041.aspx [URL accessed Oct 2019]
Lee, Chad and James Herbek. 2004. Late-season Frost Damage to Corn Grown for Silage. Univ. Kentucky Extension. AGR-183. http://www2.ca.uky.edu/agc/pubs/agr/agr183/agr183.pdf [URL accessed Oct 2019]
Maier, Dirk and Samuel Parsons. 1996. Harvesting, Drying, and Storing Frost-damaged Corn and Soybeans. Grain Quality Task Force, Purdue Univ. Extension. Fact Sheet #27. https://www.extension.purdue.edu/extmedia/GQ/GQ-27.html [URL accessed Oct 2019]
Nielsen, R.L. (Bob). 2019a. Grain Fill Stages in Corn. Corny News Network, Purdue Univ. Extension. http://www.king.corn/news/timeless/GrainFill.html [URL accessed Oct 2019]
Nielsen, R.L. (Bob). 2019b. Stress During Grain Fill: A Harbinger of Stalk Health Problems. Corny News Network, Purdue Univ. Extension. http://www.kingcorn.org/news/timeless/StalkHealth.html [URL accessed Oct 2019]
Singh, Maninder and Kim Cassida. 2019. Management guidelines for immature and frosted corn silage. Michigan State Univ. Extension. https://www.canr.msu.edu/news/management-guidelines-for-immature-and-frosted-corn-silage [URL accessed Oct 2019]
Thomison, Peter. 2019. Late-season Frost Effects on Corn: Grain Production. Agronomic Crops Network, Ohio State Univ. https://agcrops.osu.edu/newsletter/corn-newsletter/2019-33/late-season-frost-effects-corn-grain-production-adapted-dr-j [URL accessed Oct 2019]
